Low pressure Smart Ceramic Pressure Transducer for Air compressor (Sell Well ) HPT-12

Instruction:

HPT-12 series pressure sensor/transmitter applied in the refrigeration & compressor industry adopts the ceramic piezoresistive technology and the advanced circuit design to avoid influences on the product caused by the temperature, humidity, mechanical fatigue and medium, thus to improve its permanent stability in the industrial environment.

This product adopts high quality stainless steel structure, pressure core body and sensor chips are imported from Germany.

Features:

The original German imports of core body

Compact design ,easy installation

Design for air compressor applications

Strong applicability

Applications:

Air compressor

Hydraulic and Pneumatic system

Oil pressure

Industrial process control

Specifications( Refer to 25℃ )

Sensor Type	Ceramic sensor	Operable Temp.(℃)	-20~125℃
Wetted parts	Ceramic	Compensation Temp(℃)	-20~85℃
Housing	304 Stainless steel	Storage Temp(℃)	-40℃…125℃
Sealing method	O-ring	Long term stability	±0.10%FS(annual)
Power supply	12-36V DC(24V standard)	Zero error(%FS)	±0.5%
Compensated temp.	-20-85℃	Full range error(%FS)	±0.5%
Load impedance	500Ω	Thermal Zero drift(%FS)*	±2.0%
Pressure port	See below code description	Thermal Span drift(%FS)*	±2.0%
Pressure port	See below code description	Input Voltage / Output	See below code description
Accuracy (Combined Non-linearity, Hysteresis and Non-repeatability)%FS	0.5%(Typical)	Response time	＜1mS
	0.5%(Typical)	Insulation	Min1MΩ @250VDC&25℃
Pressure Range(psi)	0-5,…,750	Shock	100g,11msec
Over pressure	3X Full Range	Noise	< 2m VRMS
Burst pressure	4X Full Range or 20kpsi which is less	Pressure reference	Absolute Gauge
Life	>10⁷ Full Range Pressure	Weight	90g Max.

HPT-12 pressure transducer model code
Model	Description
HPT-12	Air compressor transmitter
	Range/Code	Pressure unit
	0-X B	Bar
	0-X M	Mpa
	0-X S	PSI
		Code	Output Signal
		E	4-20mA two wire
		W	0.5V-4.5V DC
		Z	others
			Code	Accuracy (%FS)
			J2	0.25
			J3	0.5
				Code	Pressure port
				C3	G1/2
				C5	G1/4
				C7	1/4NPT
				C8	ZG1/4
				X	Customized
					Code	I/O Outlet
					B4	Metri-park(2 meters)
					B3	Direct cable
					X	Customized
						Code	Pressure reference
						A	Absolute
						G	Vent Gauge


Example:
HPT-12	10B	E	J2	C3	X	A
HPT-12	10Bar	4-20mA	0.25%	G1/2	Customized	Absolute
Model Choose:HPT-12-10B-EJ2C3XG
