Technical parameters:
Nominal diameter: 4mm~200mm

Accuracy: + 0.2%R, + 0.5%R, + 1.0%R, + 0.2%FS (4~20mA),
Tested medium: 1Cr18Ni9Ti and hard alloy without damage to the liquid,
Environmental temperature: -20 ~ +50,
Medium temperature: -20 ~ +200,
Pressure: 1.6 Mpa, 2.5Mpa, 6.3Mpa, 25Mpa,
Explosion-proof grade: Exib II BT4, Exd II BT6,
Output signal: voltage pulse, 4 ~ 20 mA (DC +24V) second line system,
Communication interface: RS-485 communication interface.
Power supply: sensor: +5V~+24VDC (external)
Transmitter: +24VDC (external), flow meter: 3.0V lithium battery (built-in)
Product features:
Wide range ;
Hard alloy bearing performance and long life;
Strong anti vibration and anti electromagnetic interference ;
Clear and intuitive LCD screen display , low power consumption.
0V lithium battery power supply can run for more than 5 years.

Shenzhen Haohua  Electronic  Co.,Ltd is commitment to research and production and sales of various kinds of sensors ,automated testing equipment in one  high -tech enterprise. Our products include pressure sensors ,liquid level sensors,
humidity and temperature  sensor, pressure transmitter ,control instrument, and non-standard test equipments are widely used
in oil industry, chemical industry ,metallurgy, electric power ,environmental protection, metering , automatic control
,manufacturing process inspection and other domain. Kinds of non-standard sensors can be made according to your requirement.
we constantly pursue the "quality first ,sincere service" business philosophy  to provide most sincere and satisfactory
services for customer at home and abroad.
